Free Standing Pillar Jib Crane

Lifting Capacity  0.5t to 16t
Arm Length  3m to 12m
Lifting Height  3m to 100m
Working Class  A3, A4, A5
Application  BZ type pillar jib crane is suitable for use in fixed places such as docks, warehouses, workshops, etc.

Product Introduction

BZ type pillar jib crane is a kind of light and small crane used with CD1 or MD1 electric hoist or chain hoist. It is mainly composed of column, swing arm and electric hoist. The lower end of the column is fixed on the concrete foundation by anchor bolts. The electric hoist runs straight on the I-beam of the swing arm and lifts heavy objects.

BZ type pillar jib crane

Technical Data

BZ Type Pillar Jib Crane
Working Class A3,A4,A5
Capacity t 0.5~16
Effective Radius m 1~8
Lifting Height 3~100
Lifting Speed m/min 0.33~8,Single or Dual Speed
Trolley Travelling Speed m/min 2~30,Single or Dual Speed
Rotation Speed r/min 0.5~1
Rotation angle ° 0~360
Power Supply 380V 50HZ 3Phase or Customized
Temperature -20~60
Protection Grade IP44~65
The above are standard parameters, and customized solutions and designs are provided according to your actual needs.


BZ type pillar jib crane is suitable for use in fixed places such as docks, warehouses, workshops, etc.
However, they are forbidden to be used in dangerous applications where is inflammable, explosive, and corrosive, etc. What’s more, pillar jib crane cannot be used to handling molten metal, toxic and inflammable and explosive materials, etc.


  • 1
    BZ type pillar jib crane has unique structure, safety and reliability. It has the characteristics of high efficiency, energy saving, time saving, labor saving and flexibility. It can be operated at will in three-dimensional space, especially in short-distance and intensive hoisting occasions. It has unique superiority over other conventional lifting equipment.



According to your needs, we can customize pillar jib crane.
